Features
- Layer 2 Features
- Link Aggregation Control Protocol (LACP)
- 4K VLAN
- GVRP (GARP VLAN Registration Protocol)
- Port Isolation
- STP/RSTP/MSTP
- IGMP Snooping
- Quality of Service
- 4 priority queues
- Support IEEE 802.1P
- DSCP QoS
- Rate limit feature
- Security Strategies
- IP-MAC-Port-VID Binding
- Access Control List (L2-L4 ACL)
- 802.1x and RADIUS Authentication
- Support DoS defend
- Port Security
- SSL and SSH encryptions
- Management
- Web-based GUI
- Command Line Interface
- SNMP v1/v2c/v3
- RMON (1,2,3,9 group)
Specification
HARDWARE FEATURES
- Interface:
* 8 10/100/1000Mbps RJ45 Ports
* (Auto Negotiation/Auto MDI/MDIX)
* 2 1000Mbps SFP Slots
* 1 Console Port
- Network Media:
* 10BASE-T: UTP category 3, 4, 5 cable (maximum 100m)
* 100BASE-TX/1000Base-T: UTP category 5, 5e, 6 or above cable (maximum 100m)
* 1000BASE-X: MMF, SMF
- Dimensions (W×D×H): 294×180×44 mm)
- Power Supply: 100-240VAC, 50/60Hz
PERFORMANCE
- Bandwidth/Backplane: 20Gbps
- MAC Address Table: 8k
- Packet Buffer Memory: 512KB
- Packet Forwarding Rate: 14.9Mpps
- Jumbo Frame: 10240 Bytes
SOFTWARE FEATURES
- Quality of Service:
* Support 802.1p CoS/DSCP priority
* Support 4 priority queues
* Queue scheduling: SP, WRR, SP+WRR
* Port/Flow- based Rate Limiting
* Voice VLAN
- L2 Features:
* IGMP Snooping V1/V2/V3
* 802.3ad LACP (Up to 8 aggregation groups, containing 8 ports per group)
* Spanning Tree STP/RSTP/MSTP
* Port isolation
* BPDU filtering/guard
* TC/Root protect
* Loop back detection
* 802.3x Flow Control
- VLAN:
* L2-L4 package filtering based on source and destination MAC address, IP address, TCP/UDP ports, 802.1p, DSCP, protocol and VLAN ID
* Time Range Based
- Security:
* IP-MAC-Port-VID Binding
* IEEE 802.1X Port/MAC Based authentication, Radius,Guest VLAN
* DoS Defence
* Dynamic ARP inspection (DAI)
* SSH v1/v2
* SSL v2/v3/TLSv1
* Port Security
* Broadcast/Multicast/Unknown-unicast Storm Control
- Management:
* Web-based GUI and CLI management
* SNMP v1/v2c/v3,compatible with public MIBs and TP-LINK private MIBs
* RMON (1, 2, 3, 9 groups)
* DHCP/BOOTP Client,DHCP Snooping,DHCP Option82
* CPU Monitoring
* Port Mirroring
* Time Setting: SNTP
* Integrated NDP/NTDP feature
* Firmware Upgrade: TFTP & Web
* System Diagnose: VCT
* SYSLOG & Public MIBS
OTHERS
- Safety & Emission: CE, FCC
- Package Contents:
* Switch
* Power Cord
* Quick Installation Guide
* Resource CD
* Rackmount Kit
* Rubber Feet
- System Requirements: Microsoft Windows 98SE, NT, 2000, XP, Vista or Windows 7, MAC OS, NetWare, UNIX or Linux
- Environment:
* Operating Temperature: 0C - 40C (32F - 104F)
* Storage Temperature: -40C - 70C (-40F - 158F)
* Operating Humidity: 10% - 90% non-condensing
* Storage Humidity: 5% - 90% non-condensing
