- Innovative energy-efficient technology saves power up to 65% - Supports IEEE 802.3x flow control for Full Duplex mode and backpressure for Half Duplex mode - Steel design, desktop or wall-mounting design - Supports QoS (IEEE 802.1p) and IGMP snooping function - Non-blocking switching architecture that forwards and filters packets at full wire-speed for maximum throughput - 9K Jumbo frame improves performance of large data transfers - Auto-MDI/MDIX eliminates the need for crossover cables - Supports MAC address auto-learning and auto-aging - Auto-negotiation ports provide smart integration between 10Mbps, 100Mbps and 1000Mbps hardware - Fanless design ensures quiet operation - Plug and Play design simplifies installation Specification HARDWARE FEATURES - Standards and Protocols: * IEEE 802.3/802.3u/ 802.3ab/ 802.3x * CSMA/CD - Interface: 5× 10/100/1000Mbps, Auto-Negotiation, Auto-MDI/MDIX Ports - External Power Supply: 100-240VAC, 50/60Hz - Dimensions (W×D×H): 99.8×98×25 mm - Fan Quantity: Fanless - LED Indicator: System Power, Link, Speed and activity indicators per port built into each RJ-45 port - Power Consumption: max. 2.46W (220V/50Hz) SOFTWARE FEATURES - Advanced Features: * Green Technology, saving power up to 65% * 802.3X Flow Control, supports QoS (IEEE802.1P), IGMP Snooping function - Transfer Method: Store and Forward OTHERS - Package Contents: * 5-Port 10/100/1000Mbps Desktop Switch * Power Adapter * User Guide - System Requirements: Microsoft Windows 98SE, NT, 2000, XP, Vista or Windows 7, Mac OS, NetWare, UNIX or Linux - Environment: * Operating Temperature: 0C - 40C (32F - 104F) Storage Temperature: -40C - 70C (-40F - 158F) Operating Humidity: 10% - 90% non-condensing Storage Humidity: 5% - 90% non-condensing
