- 24 10/100/1000Mbps ports provide instant large file transfers - Innovative energy-efficient technology reduces power consumption by up to 40% - IEEE 802.3x flow control provides reliable data transfers - 10K Jumbo frame improves performance of large data transfers - Effective network monitoring via Port Mirroring, Loop Prevention and Cable Diagnostics - Port and tag-based QoS enable smooth latency-sensitive traffic - Abundant VLAN features improve network security via traffic segmentation - IGMP Snooping optimizes multicast applications - Centrally manage all Easy Smart Switches with Easy Smart Configuration Utility HARDWARE FEATURES - Standards and Protocols: IEEE 802.3, IEEE 802.3u, IEEE 802.3ab, IEEE 802.3x, IEEE 802.1q, IEEE 802.1p - Interface: * 24 10/100/1000Mbps RJ45 Ports * AUTO Negotiation/AUTO MDI/MDIX - Network Media: * 10BASE-T: UTP category 3, 4, 5 cable (maximum 100m) * EIA/TIA-568 100Ohm STP (maximum 100m) * 100BASE-TX: UTP category 5, 5e cable (maximum 100m) * EIA/TIA-568 100Ohm STP (maximum 100m) * 1000BASE-T: UTP category 5, 5e, 6 or above cable (maximum 100m) * EIA/TIA-568 100Ohm STP (maximum 100m) - Fan Quantity: Fanless - Power Supply: 100-240VAC, 50/60Hz - Dimensions (W×D×H): 294×180×44 mm - Power Consumption: Maximum: 19.2W (220V/50Hz) PERFORMANCE - Switching Capacity: 48Gbps - Packet Forwarding Rate: 35.7Mpps - MAC Address Table: 8K - Packet Buffer Memory: 512KB - Jumbo Frame: 10240Bytes SOFTWARE FEATURES - Quality of Service: * Support Port Based/802.1p Based priority * Support 4 priority queues * Rate Limit * Storm Control - L2 Features: * IGMP Snooping * Link Aggregation * Port Mirroring * Cable Diagnostics * Loop Prevention - VLAN: * Supports up to 32 VLANs simultaneously (out of 4K VLAN IDs) * MTU/Port/Tag VLAN - Transmission Method: Store-And-Forward OTHERS - System Requirements: Microsoft Windows 98SE, NT, 2000, XP, Vista Windows 7 or Windows 8, MAC OS, NetWare, UNIX or Linux - Environment: * Operating Temperature: 0C - 40C (32F - 104F) * Storage Temperature: -40C - 70C (-40F - 158F) * Operating Humidity: 10% - 90% non-condensing * Storage Humidity: 5% - 90% non-condensing
