Features - All ports support Full/half duplex transfer mode for 10Mbps/100Mbps and Full duplex transfer mode for 1000Mbps - Supports Auto-MDI/MDIX function - Supports IEEE 802.3X flow control for full-duplex mode and back pressure flow control for half-duplex mode - Store and forward Switching scheme Specifications - Standards and Protocols: * IEEE802.3, 802.3u, 802.3ab, 802.3x * CSMA/CD, TCP/IP - Basic Function: * Wire-speed Performance * MAC Address Auto-Learning and Auto-aging * IEEE802.3x flow control for Full-Duplex Mode and backpressure for Half-Duplex Mode - Backbound Bandwidth: 48Gbps - MAC Address Table: 8k - Forwarding Rate: * 10BASE-T: 14880pps/port * 100BASE-TX: 148800pps/port * 1000BASE-T: 1488000pps/port - Transmission Method: Store-and-Forward - Ports: 24× 10/100/1000Mbps Auto-Negotiation RJ45 ports (Auto MDI/MDIX) - Network Media: * 10Base-T: UTP category 3, 4, 5 cable (max. 100m) * EIA/TIA-568 100 STP (max. 100m) * 100Base-Tx: UTP category 5, 5e cable (max. 100m) * EIA/TIA-568 100 STP (max. 100m) * 1000Base-T: UTP category 5, 5e cable (max. 100m) - LED Indicators: Power, Link/Act (1000Mbps, 10/100Mbps) - Safety & Emission: FCC, CE - Dimensions (W×D×H): 250×158×44 mm - Environment: * Operating Temperature: 0C - 40C (32F - 104F) * Storage Temperature: -40C - 70C (-40F - 158F) * Operating Humidity: 10% - 90% non-condensing * Storage Humidity: 5% - 90% non-condensing - Power: 100-240VAC, 50/60Hz
