- Supports PoE power up to 15.4W for each PoE port - Supports PoE power up to 53W for all PoE ports - Supports PoE IEEE 802.3af compliant PDs - Supports IEEE 802.3x flow control for Full-duplex Mode and backpressure for Half-duplex Mode - 8K entry MAC address table of the TL-SG1008P with auto-learning and auto-aging - LED indicators for monitoring power, link, activity and speed - External power adapter supply HARDWARE FEATURES - Interface: 8× 10/100/1000Mbps RJ45 Ports, AUTO Negotiation/AUTO MDI/MDIX - Network Media: * 10BASE-T: UTP category 3, 4, 5 cable (maximum 100m) * EIA/TIA-568 100ohm STP (maximum 100m) * 100BASE-TX: UTP category 5, 5e cable (maximum 100m) * EIA/TIA-568 100ohm STP (maximum 100m) * 1000BASE-T: UTP category 5, 5e, 6 or above cable (maximum 100m) * EIA/TIA-568 100ohm STP (maximum 100m) - Fan Quantity: Fanless - Dimensions (W×D×H): 171×98×27 mm - Power Consumption: * Maximum (PoE on): 63.0W (220V/50Hz) * Maximum (PoE off): 3.3W (220V/50Hz) - External Power Supply: External Power Adapter(Output: 48VDC / 1.25A) - PoE Ports (RJ45): * Standard: 802.3 af compliant * PoE Ports: Port1- Port4 * Power Supply: 53W - Backbound Bandwidth: 16Gbps - Mac Address Table: 8K - Buffer Size: 2Mbits SOFTWARE FEATURES - Transmission Method: Store-And-Forward - Advanced Functions: * Compatible With IEEE 802.3af Compliant PDs * Priority Function * Mac Address Auto-Learning And Auto-Aging * IEEE802.3x Flow Control For Full-Duplex Mode And Backpressure For Half-Duplex Mode OTHERS - Certification: FCC, CE, RoHS - Consumption: * 5.8 watts (max. no PD connected) * 58.8 watts (max. with 53w PD connected) - Environment: * Operating Temperature: 0C - 40C (32F - 104F) * Storage Temperature: -40C - 70C (-40F - 158F) * Operating Humidity: 10% - 90% non-condensing * Storage Humidity: 5% - 90% non-condensing
