Key Features - Complies with IEEE 802.3 10Base-T, IEEE 802.3u 100Base-TX, IEEE 802.3ab 1000Base-T, IEEE 802.3z 1000Base-SX/LX - TP port supports 10/100/1000Base-T auto-negotiation and auto-MDI/MDI-X - 1000Base-SX: 50/125 or 62.5/125 multi-mode fiber cable, up to 220/550m - 1000Base-T: 2-pair Cat. 5/5e/6 UTP cable, up to 100 meters - Auto-Negotiation for 10/100/1000Base-T; Half-Duplex or Full-Duplex for 10Mbps and 100Mbps - Layer 2 key Feature: * IEEE 802.3x Full-Duplex Flow-Control and Back-Pressure in Half-Duplex eliminate the loss of packets * Support auto MDI/MDI-X function * Store-and-Forward mechanism * Non-blocking full wire-speed forwarding rate - Media conversion between 10/100/1000Base-T and 1000Base-SX/LX - Fiber media allows: * Multi-mode fiber using SC/LC/WDM connector * Single-mode fiber using SC/LC/WDM connector - Compacts size for easy installation and working with PLANET MC family Media Chassis (MC-700 / MC-1000R / MC-1500) - Wall-Mountable design - LED indicators for easy network diagnose - Choice of fiber-connector from SC, LC and WDM, multi-mode / single-mode fiber for 1000Base SFP interface - 9K Jumbo Frame Supported - OAM TS-1000 supported Specification HARDWARE SPECIFICATION - Standards: IEEE 802.3, 10Base-T IEEE 802.3u, 100Base-TX IEEE 802.3ab, 1000Base-T IEEE 802.3z, 1000Base-SX / LX - Ports: 1× 10/100/1000Base-T port 1× 1000Base-SX / LX port - Copper Interface: RJ-45 port (Auto-MDI / MDI-X) Twisted Pair - Optic Interface: SC / Multi-mode - Optic Wavelength: 850nm - Launch Power (dBm) max.: -4 - Launch Power(dBm) min.: -9.5 - Receive Sensitivity (dBm): -13.5 - max. Input power (dBm): -18 - Speed-Twisted-pair: 10/20Mbps for Half / Full-Duplex 100/200Mbps for Half / Full-Duplex 2000Mbps for Full-Duplex - Speed-Fiber-optic: 2000Mbps for Full-Duplex - Cable-Twisted-pair: 10Base-T: 2-pair UTP Cat. 3, 4,5, up to 100m 100Base-TX: 2-pair UTP Cat. 5, up to 100m 1000Base-T: 4-pair STP Cat 5 up to 100m - Cable-Fiber-optic cable: * 50/125 or 62.5/125 multi-mode fiber cable, up to 220/550m * 9/125 single-mode cable, provides long distance for 10 / 15 / 20 / 30 / 40 / 50 / 60 / 70 / 120km (very on fiber transceiver or SFP module) - LED Indicators: * PWR * TP LINK / ACT, 1000 * Fiber LINK / ACT - OAM: TS-1000 - Jumbo Packet Size: 9K - Power Consumption: 5.6 Watts / 19 BTU (max.) - Power Input: DC 5V / 2A - Dimension (W×D×H): 97×69×26 mm - Operating Environment: * Temperature: 0-50 Degree C * Humidity: 5-90% non-condensing - Storage Environment: * Temperature: -40 - 70 Degree C * Humidity: 5-90% non-condensing - Emission: FCC Class A, CE Class A
