Features - Supports IEEE 802.3x flow control for Full Duplex mode and backpressure for half-duplex mode - Supports MAC address auto-learning and auto-aging - LED indicators for monitoring power, link, activity - Plastic case, desktop or wall-mounting design - External Power Adapter supply Specifications - Standards and Protocols: IEEE802.3, 802.3u, 802.3x, CSMA/CD, TCP/IP - Basic Function: * Wire-speed Performance * MAC Address Auto-Learning and Auto-aging * IEEE802.3x flow control for Full-Duplex Mode and backpressure for Half-Duplex Mode - Backbound Bandwidth: 1.6Gbps - MAC Address Table: 1k - Forwarding Rate: * 10BASE-T: 14880pps/port * 100BASE-TX: 148800pps/port - Transmission Method: Store-and-Forward * Ports: 8× 10/100Mbps Auto-Negotiation RJ45 ports (Auto MDI/MDIX) - Network Media: * 10Base-T: UTP category 3, 4, 5 cable (max. 100m); EIA/TIA-568 100 Ohm STP (max. 100m) * 100Base-Tx: UTP category 5, 5e cable (max. 100m); EIA/TIA-568 100 Ohm STP (max. 100m) - LED Indicators: Power, Link/Act (1-8) - Safety & Emission: FCC, CE - Dimensions (W×D×H): 140×87×27.5 mm - Environment: * Operating Temperature: 0C - 40C (32F - 104F) * Storage Temperature: -40C - 70C (-40F - 158F) * Operating Humidity: 10% - 90% non-condensing * Storage Humidity: 5% - 90% non-condensing - Power: External Power Adapter
